1 - FIELDCASE
BDE-648076-01
648076-01
|
£14.57
|
£17.48
|
|
|
2 - FIELD SA 230V GB
BDE-N048005
N048005
|
-
|
|
|
|
2 - FIELD SA 115V LX
BDE-N048002
N048002
|
£43.02
|
£51.63
|
|
|
3 - SCREW
BDE-N068183.A3
N068183
|
£3.80
|
£4.56
|
|
|
4 - CLAMSHELL SET
BDE-662717-01
662717-01
|
£25.05
|
£30.06
|
|
|
5 - BAFFLE FAN
BDE-650300-00
650300-00
|
£1.42
|
£1.70
|
|
|
6 - ARMATURE 115V LX
BDE-647864-02SV.A2
647864-02SV
|
£84.42
|
£101.30
|
|
|
6 - ARMATURE 230V GB
BDE-647864-03SV.A2
647864-03SV
|
£71.44
|
£85.73
|
|
|
7 - BEARING LX
BDE-330003-60.A124
330003-60
|
£2.78
|
£3.34
|
|
|
7 - BEARING & SEAL GB
BDE-391032-00.A13
391032-00
|
£3.80
|
£4.56
|
|
|
7 - BOOT LX
BDE-631563-00.A17
631563-00
|
£1.50
|
£1.80
|
|
|
8 - BRUSH HOLDER SA LX
BDE-653892-01.A1
653892-01
|
£4.69
|
£5.63
|
|
|
8 - BRUSH HOLDER GB
BDE-N028784SV.A3
N028784SV
|
£18.91
|
£22.69
|
|
|
9 - CORD PROTECTOR
BDE-N542553.A423
N542553
|
£3.80
|
£4.56
|
|
|
10 - SWITCH SA LX
BDE-N079272.A2
N079272
|
£78.12
|
£93.74
|
|
|
10 - SWITCH SA GB
BDE-N113355SV.A0
N113355SV
|
£41.24
|
£49.49
|
|
|
11 - CORD CLAMP
BDE-655058-00.A4
655058-00
|
£1.50
|
£1.80
|
|
|
12 - PLASTIC SCREW
BDE-330065-31.A96
330065-31
|
£1.50
|
£1.80
|
|
|
13 - SCREW
BDE-330045-15.A19
330045-15
|
£1.50
|
£1.80
|
|
|
14 - SCREW
BDE-330065-07.A50
330065-07
|
£1.50
|
£1.80
|
|
|
15 - SCREW
BDE-176951-00.A24
176951-00
|
£1.50
|
£1.80
|
|
|
18 - CORDSET LX
BDE-330061-37.A2
330061-37
|
£38.80
|
£46.56
|
|
|
18 - CORDSET (M/PLUG) GB GB
BDE-330120-93.A3
330120-93
|
£24.39
|
£29.27
|
|
|
19 - RATING PLATE LX
BDE-N097980
N097980
|
£2.71
|
£3.25
|
|
|
19 - RATING PLATE GB
BDE-N097981
N097981
|
£2.71
|
£3.25
|
|
|
20 - BRAND LABEL
BDE-395047-00.A4
395047-00
|
£1.50
|
£1.80
|
|
|
21 - HANDLE SIDE SA
BDE-663029-00.A0
663029-00
|
£24.39
|
£29.27
|
|
|
22 - SPRING LX
BDE-662999-00.A0
662999-00
|
£1.50
|
£1.80
|
|
|
22 - SPRING GB
BDE-662999-01.A5
662999-01
|
£1.50
|
£1.80
|
|
|
23 - BRUSH 115V LX
BDE-N032696
N032696
|
-
|
|
|
|
23 - BRUSH 230V GB
BDE-N032699
N032699
|
-
|
|
|
|
24 - BRUSH 115V LX
BDE-N032697
N032697
|
-
|
|
|
|
24 - BRUSH 230V GB
BDE-N032700
N032700
|
-
|
|
|
|
25 - BEARING
BDE-N339299.A4
N339299
|
£3.80
|
£4.56
|
|
|
30 - GEARCASE SA
BDE-N081294
N081294
|
£43.02
|
£51.63
|
|
|
31 - BEARING NEEDLE
BDE-330004-01.A10
330004-01
|
£3.80
|
£4.56
|
|
|
32 - PIN
BDE-330041-07.A8
330041-07
|
£1.50
|
£1.80
|
|
|
33 - GEARCASE COVER
BDE-645400-04SV.A2
645400-04SV
|
£30.08
|
£36.10
|
|
|
34 - BEARING
BDE-605040-02.A142
605040-02
|
£2.26
|
£2.71
|
|
|
35 - BEARING NEEDLE
BDE-330004-02.A34
330004-02
|
£1.50
|
£1.80
|
|
|
36 - THRUST PLATE
BDE-652185-00.A4
652185-00
|
£1.50
|
£1.80
|
|
|
37 - O RING
BDE-99014-04.A4
99014-04
|
-
|
|
|
|
41 - O RING
BDE-56122-00.A3
56122-00
|
£1.50
|
£1.80
|
|
|
43 - SCREW
BDE-330045-74.A1
330045-74
|
£1.50
|
£1.80
|
|
|
46 - CHUCK KEYLESS TORQUE TO 80-85 NM
BDE-586200-12.A2
586200-12
|
£84.42
|
£101.30
|
|
|
49 - SEAL
BDE-648761-00.A1
648761-00
|
£1.50
|
£1.80
|
|
|
55 - FELT
BDE-N063107.A3
N063107
|
£3.30
|
£3.96
|
|
|
56 - NO LONGER AVAILABLE
BDE-000000-00.A96521
000000-00
|
-
|
|
|
|
61 - DEPTH STOP
BDE-940357-00.A37
940357-00
|
£17.48
|
£20.97
|
|
|
62 - END CAP
BDE-N030304.A2
N030304
|
£17.48
|
£20.97
|
|
|
63 - COLLAR
BDE-655856-00.A2
655856-00
|
£10.85
|
£13.02
|
|
|
64 - SPINDLE
BDE-656368-02SV.A4
656368-02SV
|
£74.15
|
£88.98
|
|
|
66 - SPRING
BDE-651266-00.A2
651266-00
|
£1.50
|
£1.80
|
|
|
67 - RATCHET
BDE-651262-00.A2
651262-00
|
£4.69
|
£5.63
|
|
|
68 - SPRING
BDE-656287-00.A1
656287-00
|
£1.50
|
£1.80
|
|
|
69 - ARM
BDE-659192-00.A2
659192-00
|
£4.69
|
£5.63
|
|
|
70 - CIRCLIP
BDE-652188-00.A1
652188-00
|
£1.50
|
£1.80
|
|
|
71 - SPRING GUIDE
BDE-395460-00.A38
395460-00
|
£1.50
|
£1.80
|
|
|
72 - PIN
BDE-648298-00.A0
648298-00
|
£1.50
|
£1.80
|
|
|
73 - BRACKET
BDE-651331-00.A2
651331-00
|
£1.50
|
£1.80
|
|
|
74 - FINGER
BDE-656286-00.A3
656286-00
|
£1.50
|
£1.80
|
|
|
75 - SPRING
BDE-652003-00.A2
652003-00
|
£1.50
|
£1.80
|
|
|
76 - WASHER THRUST
BDE-652004-00.A2
652004-00
|
£1.50
|
£1.80
|
|
|
77 - GEAR
BDE-653728-00.A3
653728-00
|
£16.03
|
£19.24
|
|
|
78 - SELECTOR
BDE-643924-00SV.A0
643924-00SV
|
£37.35
|
£44.82
|
|
|
79 - ROLLER
BDE-651330-00.A2
651330-00
|
£1.50
|
£1.80
|
|
|
80 - YOKE
BDE-N045436.A1
N045436
|
£1.50
|
£1.80
|
|
|
81 - SPRING
BDE-N031370.A3
N031370
|
£1.50
|
£1.80
|
|
|
82 - SPRING
BDE-N022914.A4
N022914
|
£1.50
|
£1.80
|
|
|
83 - WASHER THRUST
BDE-659185-00.A2
659185-00
|
£1.50
|
£1.80
|
|
|
84 - INTER SHAFT INCL 85
BDE-N045500SV.A3
N045500SV
|
£41.24
|
£49.49
|
|
|
85 - GEAR
BDE-643896-00.A4
643896-00
|
£16.03
|
£19.24
|
|
|
86 - CLUTCH SA
BDE-653814-00SV.A2
653814-00SV
|
£55.30
|
£66.36
|
|
|
87 - WASHER THRUST
BDE-652007-00.A2
652007-00
|
£1.50
|
£1.80
|
|
|
90 - PIN
BDE-651334-00.A2
651334-00
|
£3.80
|
£4.56
|
|
|
91 - PIN
BDE-656321-00.A1
656321-00
|
£1.50
|
£1.80
|
|
|
92 - BEARING
BDE-605040-72.A2
605040-72
|
£5.88
|
£7.06
|
|
|
93 - CIRCLIP
BDE-658952-00.A1
658952-00
|
£1.50
|
£1.80
|
|
|
94 - CAPACITOR
BDE-N075085.A2
N075085
|
£7.18
|
£8.62
|
|
|
95 - WASHER THRUST
BDE-N045430.A2
N045430
|
£1.50
|
£1.80
|
|
|
800 - GREASE
BDE-429698-00.A89
429698-00
|
£84.42
|
£101.30
|
|
|
800 - GREASE
BDE-286436-00.A152
286436-00
|
£126.63
|
£151.96
|
|
|
836 - S.T.CHUCK REMOVAL JIG
BDE-559662-99.A12
559662-99
|
£58.69
|
£70.43
|
|
|
836 - S.T.CHUCK REMOVAL JIG
BDE-1003939-99.A2
1003939-99
|
£135.36
|
£162.43
|
|
|
861 - KITBOX
BDE-N079829.A3
N079829
|
£45.14
|
£54.17
|
|
