2 - DRILL CHUCK 13VLRE-N (KEYLESS TYPE)
HIT-319546.A6
319546
|
-
|
|
|
|
3 - SPINDLE
HIT-325319.A0
325319
|
-
|
|
|
|
4 - RETAINING RING FOR D35 HOLE (10 PCS.)
HIT-939556.A0
939556
|
£11.82
|
£14.18
|
|
|
5 - OIL SEAL (A)
HIT-971745.A2
971745
|
£5.27
|
£6.32
|
|
|
6 - DISTANCE RING
HIT-325335.A0
325335
|
£1.67
|
£2.00
|
|
|
7 - BALL BEARING 6202DD
HIT-6202DD.A12
6202DD
|
£7.32
|
£8.78
|
|
|
8 - RATCHET (A)
HIT-325330.A0
325330
|
-
|
|
|
|
9 - SPRING (A)
HIT-984101.A4
984101
|
£1.67
|
£2.00
|
|
|
10 - TAPPING SCREW D5X55
HIT-325336.A0
325336
|
-
|
|
|
|
11 - GEAR COVER
HIT-325326.A0
325326
|
-
|
|
|
|
12 - WASHER (B)
HIT-322852.A4
322852
|
£1.67
|
£2.00
|
|
|
*13 - SECOND PINION AND GEAR SET
HIT-325339.A0
325339
|
-
|
|
|
|
*13 - SECOND PINION AND GEAR SET FOR SLIP CLUTCH
HIT-325340.A0
325340
|
-
|
|
|
|
14 - CHANGE LEVER
HIT-325323.A0
325323
|
£1.67
|
£2.00
|
|
|
15 - CHANGE COVER
HIT-325324.A0
325324
|
-
|
|
|
|
16 - CHANGE SHAFT
HIT-325322.A0
325322
|
-
|
|
|
|
17 - INNER COVER
HIT-325320.A0
325320
|
-
|
|
|
|
18 - SHIFT LEVER ASS'Y INCLUD.19-21
HIT-322847.A3
322847
|
£4.99
|
£5.99
|
|
|
19 - O-RING (S-22)
HIT-306353.A2
306353
|
£1.67
|
£2.00
|
|
|
20 - SHIFT PIN
HIT-322848.A0
322848
|
£1.67
|
£2.00
|
|
|
21 - SHIFT LEVER
HIT-000000.A4542
000000
|
-
|
|
|
|
22 - SPRING (H)
HIT-981328.A0
981328
|
£1.67
|
£2.00
|
|
|
23A - STEEL BALL D3.5 (10 PCS.)
HIT-335299.A6
335299
|
£1.67
|
£2.00
|
|
|
24 - RETAINING RING (E-TYPE) FOR D15 SHAFT
HIT-323048.A4
323048
|
£1.67
|
£2.00
|
|
|
25 - RATCHET (B)
HIT-325331.A0
325331
|
-
|
|
|
|
26 - SPRING
HIT-325332.A0
325332
|
-
|
|
|
|
27 - SLEEVE (A)
HIT-325333.A0
325333
|
-
|
|
|
|
28 - O-RING
HIT-884909.A0
884909
|
-
|
|
|
|
29 - SLEEVE (B)
HIT-325334.A0
325334
|
-
|
|
|
|
30 - SHIFT ARM
HIT-322849.A3
322849
|
£1.67
|
£2.00
|
|
|
31 - PIN D5X68
HIT-325321.A0
325321
|
-
|
|
|
|
32 - GEAR
HIT-325327.A0
325327
|
-
|
|
|
|
33 - BRAND LABEL
HIT-000000.A4456
000000
|
-
|
|
|
|
34 - NAME PLATE
HIT-000000.A4457
000000
|
-
|
|
|
|
35 - BALL BEARING 608DD
HIT-608DDM.A7
608DDM
|
£6.35
|
£7.62
|
|
|
36 - RETAINING RING FOR D22 HOLE (10 PCS.)
HIT-939553.A0
939553
|
-
|
|
|
|
*37 - ARMATURE 110V
HIT-360652C.A0
360652C
|
£40.43
|
£48.52
|
|
|
*37 - ARMATURE 230V
HIT-360652E.A2
360652E
|
£40.43
|
£48.52
|
|
|
38 - FAN GUIDE
HIT-325325.A0
325325
|
£1.67
|
£2.00
|
|
|
39 - HEX. HD. TAPPING SCREW D4X50
HIT-961672.A9
961672
|
-
|
|
|
|
*40 - STATOR 110V
HIT-340650C.A0
340650C
|
-
|
|
|
|
*40 - STATOR 230V
HIT-340650E.A0
340650E
|
-
|
|
|
|
41A - BALL BEARING 698VVC2
HIT-698VVC.A2
698VVC
|
£5.05
|
£6.06
|
|
|
42 - RUBBER BUSHING
HIT-309929.A8
309929
|
£1.67
|
£2.00
|
|
|
43A - BRAND PLATE
HIT-325338.A0
325338
|
-
|
|
|
|
44 - HOUSING
HIT-324553.A1
324553
|
£30.96
|
£37.15
|
|
|
45 - PUSHING BUTTON
HIT-322853.A15
322853
|
£1.67
|
£2.00
|
|
|
46 - SWITCH (1P PILLAR TYPE)
HIT-325337.A0
325337
|
-
|
|
|
|
47 - CORD ARMOR D8.8
HIT-953327.A5
953327
|
£1.67
|
£2.00
|
|
|
48 - CORD CLIP
HIT-937631.A144
937631
|
£1.67
|
£2.00
|
|
|
49 - TAPPING SCREW (W/FLANGE) D4X16
HIT-984750.A10
984750
|
£1.67
|
£2.00
|
|
|
50 - CARBON BRUSH (1 PAIR)
HIT-999041.A16
999041
|
£5.54
|
£6.65
|
|
|
51 - BRUSH HOLDER
HIT-955203.A19
955203
|
£4.16
|
£4.99
|
|
|
*52 - CHOKE COIL (BLUE) 110V-240V
HIT-321634.A3
321634
|
£9.43
|
£11.32
|
|
|
*52 - CHOKE COIL (BLUE) 110V FOR GBR (110V)
HIT-322519.A1
322519
|
£8.74
|
£10.49
|
|
|
*53 - CHOKE COIL (BROWN) 220V-240V
HIT-322517.A1
322517
|
£11.35
|
£13.62
|
|
|
*53 - CHOKE COIL (BROWN) 110V FOR GBR (110V)
HIT-322518.A3
322518
|
£11.35
|
£13.62
|
|
|
*54 - CORD (CORD ARMOR D8.8) FOR GBR (230V)
HIT-500435Z.A59
500435Z
|
£14.14
|
£16.97
|
|
|
*54 - CORD (CORD ARMOR D8.8) FOR GBR (110V)
HIT-500461Z.A46
500461Z
|
£15.56
|
£18.67
|
|
|
55 - HANDLE COVER
HIT-324554.A0
324554
|
£16.80
|
£20.16
|
|
|
56 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A49
301653
|
£1.67
|
£2.00
|
|
|
57 - EARTH TERMINAL
HIT-992635.A18
992635
|
£1.67
|
£2.00
|
|
|
501 - CASE
HIT-325341.A0
325341
|
-
|
|
|
|
502 - SIDE HANDLE
HIT-323050.A2
323050
|
£28.41
|
£34.09
|
|
|
503 - DEPTH GAUGE
HIT-303709.A53
303709
|
£1.67
|
£2.00
|
|
|
58 - NOISE SUPPRESSOR
HIT-994273.A73
994273
|
£7.30
|
£8.76
|
|
|
608 - DRILL BIT (B) D16.0X160
HIT-971670.A5
971670
|
-
|
|
|
