Hitachi / Hikoki TPH-230S Engine Pole Hedge Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TPH-230S Engine Pole Hedge Trimmer

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y TILL G105470 HIT-6687468.A17 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A26 6699328	£5.70	£6.84
3 - CYLINDER SET HIT-6685489.A12 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A24 6684586	-
5 - CYLINDER GASKET HIT-6685709.A6 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A14 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A4 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A116 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A23 6696944	£5.61	£6.73
10A - CRANK SHAFT COMP. HIT-6686217.A9 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L TILL G105470 HIT-6687888.A12 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A3 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y TILL G105470 HIT-6699772.A9 6699772	-
14A - IGNITION COIL ASS'Y SINCE G105471 HIT-6697638.A10 6697638	-
15 - RUBBER CAP TILL G105470 HIT-6684602.A35 6684602	-
16 - LEAD WIRE ASS'Y HIT-6697836.A0 6697836	-
17 - WOODRUFF KEY 3X13X4.5 TILL B023900 HIT-6684899.A107 6684899	-
*31 - GEAR SHAFT SHIM 0.10 HIT-6689177.A35 6689177	-
*31 - GEAR SHAFT SHIM 0.15 HIT-6689178.A0 6689178	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A67 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A14 6684605	-
32 - CRANK CASE ASS'Y TILL A023000 HIT-6695806.A6 6695806	£38.60	£46.32
32A - CRANK CASE ASS'Y SINCE A023001 HIT-6686585.A12 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A91 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A110 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A4 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A69 6684586	-
37 - MAGNETO ROTOR COMP TILL B023900 HIT-6687376.A4 6687376	-
37A - MAGNETO ASS'Y TILL G105470 HIT-6601171.A4 6601171	-
37B - MAGNETO ROTOR COMP. SINCE G105471 HIT-6696928.A10 6696928	£50.30	£60.36
38 - BOLT WASHER M8 HIT-6684611.A84 6684611	-
39 - HEX. NUT M8 HIT-6684612.A32 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A6 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A3 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A33 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A19 6695514	-
55 - SCREW 5X60/S HIT-6695354.A7 6695354	£1.67	£2.00
56 - WASHER 5 HIT-6684661.A70 6684661	£1.67	£2.00
57 - SHIELD TUBE HIT-6688174.A8 6688174	£3.85	£4.62
58 - CLIP D6 HIT-6685198.A25 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A20 66A3864	-
60 - TANK 1 HIT-6691592.A11 6691592	£11.38	£13.66
61 - TANK CAP ASS'Y HIT-6685049.A44 6685049	£9.94	£11.93
62 - COLLAR 5.8 TILL G104400 HIT-6692244.A58 6692244	£1.67	£2.00
63 - CARBURETOR SET WYL189 TILL B023900 HIT-6690513.A4 6690513	£43.64	£52.37
63A - CARBURETOR SET WYL182 SINCE B023901 HIT-6690512.A8 6690512	£69.17	£83.00
64 - SWIVEL CAP SINCE B122851 HIT-6691337.A61 6691337	£1.67	£2.00
65 - HEX. HOLE BOLT 5X16/PS TILL G104400 HIT-6695504.A21 6695504	£1.67	£2.00
65A - BOLT (W/FLANGE) L17.8 SINCE G104401 HIT-6696574.A13 6696574	£1.67	£2.00
66 - SCREW 5X20WS TILL G104400 HIT-6695516.A8 6695516	-
66A - BOLT (W/FLANGE) L17.8 SINCE G104401 HIT-6696574.A12 6696574	£1.67	£2.00
67 - TANK CAP CHAIN HIT-6684625.A72 6684625	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A26 6684880	£1.67	£2.00
69 - RETURN GROMMET HIT-6684627.A26 6684627	£1.67	£2.00
91 - MUFFLER PROTECTOR TILL C026900 HIT-6692798.A1 6692798	-
91A - MUFFLER PROTECTOR BLACK SINCE C026901 HIT-6692809.A7 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A6 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A16 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A16 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A34 6684918	£1.67	£2.00
98 - MUFFLER SET HIT-6692487.A2 6692487	£29.28	£35.14
100 - MUFFLER GASKET HIT-6692745.A6 6692745	-
101 - HEAT SHIELD HIT-6687253.A4 6687253	£2.81	£3.37
102 - SPARK PLUG COVER 1 HIT-6688350.A3 6688350	-
103 - CLUTCH WASHER B HIT-6697619.A13 6697619	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A7 6688616	£12.82	£15.38
104A - CLUTCH ARM COMP 54 SINCE F113051 HIT-6697161.A4 6697161	-
105 - CLUTCH SPRING TILL F113050 HIT-6689430.A12 6689430	£3.89	£4.67
105A - CLUTCH SPRING SINCE F113051 HIT-6697618.A6 6697618	-
106 - CLUTCH PLATE (A) HIT-6689528.A31 6689528	£1.67	£2.00
107 - STEP BOLT TILL F113050 HIT-6689627.A28 6689627	£1.67	£2.00
107A - STEP BOLT SINCE F113051 HIT-6684646.A12 6684646	£3.72	£4.46
108 - BENT WASHER 8 HIT-6684648.A31 6684648	£1.67	£2.00
109 - CLUTCH ASS'Y SINCE F113051 HIT-6696932.A4 6696932	-
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A19 6684647	£1.67	£2.00
111 - TAPPING SCREW D4.5X20 TILL C026900 HIT-6685191.A9 6685191	-
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A15 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A10 6688011	-
114 - GROMMET TILL C026900 HIT-6688040.A2 6688040	-
116 - MUFFLER SET FOR AUS HIT-6692496.A4 6692496	-
117 - MUFFLER SPECIAL GASKET FOR AUS HIT-6692883.A15 6692883	-
118 - EXHAUST PIPE SET 1 HIT-6692709.A3 6692709	-
119 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS HIT-6685109.A15 6685109	-
120 - MUFFLER WIRE NET SET FOR AUS HIT-6692688.A3 6692688	-
131 - RECOIL STARTER BODY ASS'Y TILL C026900 HIT-6692986.A2 6692986	-
132 - STARTER HANDLE TILL C026900 HIT-6693240.A13 6693240	£16.35	£19.62
133 - RECOIL STARTER BODY COMP TILL C026900 HIT-6693038.A9 6693038	-
134 - ROPE TILL C026900 HIT-6693168.A16 6693168	£2.82	£3.39
135 - RECOIL SPRING TILL C026900 HIT-6693138.A2 6693138	£12.10	£14.52
136 - SPRING PLATE TILL Z029400 HIT-6693252.A4 6693252	-
137 - TILL Z029400 NO LONGER AVAILABLE HIT-000000.A4027 000000	-
137A - SPRING CASE ASS'Y SINCE Z029401 TILL C026900 HIT-6693101.A3 6693101	-
138 - STARTER BUSH TILL Z029400 HIT-6689170.A1 6689170	-
139 - STARTER PULLEY TILL Z029400 HIT-6693078.A0 6693078	-
139A - STARTER PULLEY SINCE Z029401 TILL C026900 HIT-6693079.A0 6693079	-
140 - SPECIAL WASHER 5.2X15 TILL C026900 HIT-6687947.A6 6687947	-
141 - TAPPING SCREW D5X14 TILL C026900 HIT-6685275.A17 6685275	-
142 - STARTER BASE TILL C026900 HIT-6693470.A3 6693470	-
143 - HEX. HOLE BOLT 4X12WS TILL C026900 HIT-6695507.A11 6695507	-
144 - SQUARE NUT 5 TILL C026900 HIT-6695176.A3 6695176	-
145 - TAPPING SCREW D4.5X14 TILL C026900 HIT-6685153.A22 6685153	-
146 - STARTER PULLEY ASS'Y TILL C026900 HIT-6693408.A1 6693408	£35.37	£42.44
151 - RECOIL STARTER BODY ASS'Y SINCE C026901 TILL F024130 HIT-6692988.A4 6692988	£53.19	£63.83
152 - STARTER HANDLE SINCE C026901 TILL F024130 HIT-6693240.A12 6693240	£16.35	£19.62
153 - RECOIL STARTER BODY COMP. SINCE C026901 TILL F024130 HIT-6693039.A1 6693039	-
154 - ROPE 2.6X830 SINCE C026901 TILL F024130 HIT-6693175.A1 6693175	-
155 - RECOIL SPRING SINCE C026901 TILL F024130 HIT-6693139.A7 6693139	-
156 - SPRING CASE ASS'Y SINCE C026901 TILL F024130 HIT-6693102.A3 6693102	-
157 - STARTER ROPE REEL SINCE C026901 TILL F024130 HIT-6693080.A7 6693080	-
158 - SPECIAL WASHER 5.2X15 SINCE C026901 TILL F024130 HIT-6687947.A5 6687947	-
159 - TAPPING SCREW D5X14 SINCE C026901 TILL F024130 HIT-6685275.A18 6685275	-
160 - HEX. HOLE BOLT 4X18WS SINCE C026901 TILL F024130 HIT-6695508.A27 6695508	£1.67	£2.00
161 - FLUNGE NUT 5 SINCE C026901 TILL F024130 HIT-6695169.A5 6695169	£1.67	£2.00
162 - STARTER PULLEY ASS'Y SINCE C026901 TILL F024130 HIT-6693408.A2 6693408	£35.37	£42.44
171B - RECOIL STARTER BODY ASS'Y INCLUD.173-179 SINCE F024131 HIT-6601570.A90 6601570	£23.15	£27.78
173 - STARTER ROPE 3.5X860 SINCE F024131 HIT-6684674.A45 6684674	£5.70	£6.84
174 - RECOIL SPRING SINCE F024131 HIT-6684675.A91 6684675	£8.82	£10.58
175A - STARTER ROPE REEL SINCE TL026141 HIT-6699997.A42 6699997	-
176 - DAMPER SPRING SINCE F024131 HIT-6684677.A52 6684677	£5.70	£6.84
177A - CAM PLATE SINCE TL026141 HIT-6699996.A47 6699996	£4.28	£5.13
178 - SET SCREW SINCE F024131 HIT-6684679.A78 6684679	£2.98	£3.57
179 - STARTER HANDLE SINCE F024131 HIT-6684680.A58 6684680	£5.87	£7.04
180 - STARTER PULLEY ASS'Y SINCE F024131 HIT-6684681.A59 6684681	£18.16	£21.79
181 - HEX. HOLE BOLT 4X18WS SINCE F024131 HIT-6695508.A28 6695508	£1.67	£2.00
182 - D4E RETAINING RING SINCE F024131 HIT-6685101.A39 6685101	-
183 - STARTER PAWL SPRING SINCE F024131 HIT-6684684.A66 6684684	£3.29	£3.95
184 - STARTER PAWL SINCE F024131 HIT-6684685.A49 6684685	£5.07	£6.08
185 - CAMPLATE ASS'Y SINCE F024131 TILL TL026140 HIT-6699691.A33 6699691	£7.75	£9.30
201 - CLEANER ASSY HIT-6690048.A4 6690048	£11.61	£13.93
202 - CLEANER COVER SET HIT-6690391.A6 6690391	£7.48	£8.97
203 - AIR CLEANER ELEMENT HIT-6684654.A6 6684654	£1.67	£2.00
204 - SPECIAL SCREW HIT-6689737.A45 6689737	-
205 - CLEANER BODY COMP. HIT-6684656.A9 6684656	£7.64	£9.17
206 - CHOKE VALVE HIT-6684657.A5 6684657	£2.81	£3.37
207 - WAVE WASHER 8 HIT-6684658.A21 6684658	£1.67	£2.00
208 - COLLAR 8 HIT-6684659.A5 6684659	-
221 - PUMP BODY COMP. HIT-6684879.A40 6684879	£35.37	£42.44
222 - PRIMING PUMP COMP. HIT-6684687.A52 6684687	£9.27	£11.12
223 - DIAPHRAGM COVER HIT-6684688.A47 6684688	£5.70	£6.84
224 - PRIMING BODY HIT-6684689.A52 6684689	£5.87	£7.04
225 - METERING DIAPHRAGM COMP. HIT-6690830.A40 6690830	£14.58	£17.50
226 - DIAPHRAGM GASKET HIT-6684691.A52 6684691	£5.70	£6.84
227 - PUMP DIAPHRAGM HIT-6684693.A111 6684693	£5.70	£6.84
228 - PUMP GASKET HIT-6691457.A69 6691457	£8.48	£10.18
229 - MAIN JET #40 TILL B023900 HIT-6691845.A10 6691845	-
229A - MAIN JET #38 SINCE B023901 HIT-6691844.A6 6691844	-
230 - O-RING HIT-6684695.A87 6684695	£1.67	£2.00
231 - STOP RING HIT-6684696.A126 6684696	-
232 - SWIVEL HIT-6684697.A60 6684697	-
233 - THROTTLE SET SCREW HIT-6684698.A43 6684698	-
234 - SET SCREW HIT-6684699.A46 6684699	-
235 - INLET SCREEN HIT-6684700.A140 6684700	-
236 - THROTTLE VALVE TILL B023900 HIT-6684883.A30 6684883	£32.24	£38.69
251 - CLUTCH SHAFT COMP. HIT-6695969.A5 6695969	£16.69	£20.03
252 - STOP RING C-12 OUTER HIT-6684664.A21 6684664	£1.67	£2.00
253 - ANTI-VIBE RUBBER HIT-6691839.A7 6691839	£5.92	£7.11
254 - HEX. HOLE BOLT 5X16 HIT-6695046.A9 6695046	£1.67	£2.00
255 - HEX. HOLE BOLT M5X25/S HIT-6684709.A53 6684709	£1.67	£2.00
256 - FAN CASE 1 HIT-6687029.A8 6687029	£26.97	£32.36
257 - PIPE HOLDER 1 HIT-6689651.A5 6689651	£8.88	£10.66
258 - WASHER M5 (BLACK) HIT-6684918.A33 6684918	£1.67	£2.00
259 - GEAR CASE WASHER HIT-6689159.A11 6689159	-
260 - METAL FITTING HIT-6689664.A40 6689664	£6.12	£7.35
281 - DRIVE SHAFT 978L HIT-6689440.A1 6689440	£50.06	£60.07
282 - DRIVE SHAFT PIPE 945L HIT-6689304.A0 6689304	-
283 - BUSH ASS'Y HIT-6697839.A9 6697839	-
284 - HEX.NUT 6 HIT-6684835.A36 6684835	£1.67	£2.00
285 - LOOP HANDLE BLACK HIT-6691046.A4 6691046	£16.30	£19.56
286 - HANDLE BRACKET A HIT-6691134.A18 6691134	£3.10	£3.72
287 - HANDLE GRIP HIT-6691098.A5 6691098	£10.90	£13.08
289 - BOLT 6X43/P (BLACK) HIT-6684838.A18 6684838	£1.67	£2.00
290 - TAPPING SCREW 5X20 HIT-6695255.A23 6695255	-
291 - BRAKE SHAFT WASHER HIT-6689681.A10 6689681	£1.67	£2.00
292 - THROTTLE LEVER ASS'Y HIT-6693769.A4 6693769	-
294 - THROTTLE WIRE COMP. HIT-6693982.A8 6693982	£36.27	£43.52
295 - THROTTLE WIRE 4T HIT-6694025.A5 6694025	£14.47	£17.36
296 - STOP BUTTON COMP. HIT-6687452.A7 6687452	£28.71	£34.45
297 - PROTECTION TUBE 7X145L HIT-6687523.A3 6687523	-
298 - TRIGGER LOCK OUT HIT-6684721.A38 6684721	£5.17	£6.20
299 - RETURN SPRING HIT-6684722.A11 6684722	£1.67	£2.00
300 - BLIND PLUG HIT-6684724.A7 6684724	-
301 - SCREW M5X20 HIT-6684803.A4 6684803	-
302 - CONTAL NUT 5 HIT-6684727.A38 6684727	£1.67	£2.00
303 - SCREW M4X20 (BLACK) HIT-6684725.A36 6684725	-
304 - THROTTLE LEVER HIT-6684804.A26 6684804	£6.86	£8.23
305 - HANGER D24 HIT-6689277.A18 6689277	-
321 - GEAR CASE A 1 HIT-6688656.A0 6688656	£50.67	£60.80
321A - GEAR CASE A 1 HIT-6688653.A12 6688653	£38.36	£46.03
322 - BALL BEARING 6901ZZ 2 HIT-6695582.A4 6695582	£15.31	£18.37
323 - STOP RING S-12 1 HIT-6695302.A16 6695302	£1.67	£2.00
324 - STOP RING C-24 1 HIT-6684732.A8 6684732	£1.67	£2.00
325 - BALL BEARING 608ZZC3 HIT-6698772.A12 6698772	£2.84	£3.41
326 - SCREW 6X8 TILL Z063200 HIT-6695458.A9 6695458	-
326A - GREASE NIPPLE COMP. SINCE Z063201 HIT-6688643.A3 6688643	£1.67	£2.00
327 - O RING P-41 TILL Z063200 HIT-6695678.A0 6695678	-
328 - SCREW 6X10P TILL Z063200 HIT-6695322.A0 6695322	-
329 - HEX. HOLE BOLT 5X10 HIT-6695042.A41 6695042	£1.67	£2.00
330 - HEX. HOLE BOLT 5X22/S TILL Z063200 HIT-6695492.A55 6695492	-
330A - HEX. HOLE BOLT M5X25/S SINCE Z063201 HIT-6684709.A55 6684709	£1.67	£2.00
331 - FLANGE BLIND NUT 8 TILL Z063200 HIT-6695149.A0 6695149	-
331A - HEX. HOLE BOLT 6X12 SINCE Z063201 HIT-6695078.A14 6695078	£1.67	£2.00
332 - SPECIAL WASHER TILL Z063200 HIT-6685856.A1 6685856	£3.85	£4.62
332A - SPECIAL WASHER B TILL D106450 HIT-6684822.A23 6684822	£1.67	£2.00
332B - SPECIAL WASHER B SINCE D106451 HIT-6684822.A24 6684822	£1.67	£2.00
333 - GEAR CASE B HIT-6695981.A6 6695981	£40.62	£48.75
334 - BALL BEARING #6000DD 1 HIT-6695528.A7 6695528	-
335 - RETAINING RING C-TYPE D26 HIT-6695294.A10 6695294	-
336 - RETAINING RING E-TYPE D6 HIT-6695310.A17 6695310	£1.67	£2.00
337 - GEAR CASE COVER (A) HIT-6689167.A3 6689167	-
338 - SCREW 4X8 TILL Z063200 HIT-6694861.A7 6694861	-
338A - HEX HOLE BOLT 4X8 SINCE Z063201 HIT-6695035.A6 6695035	-
339 - BALL BEARING 608ZZC3 HIT-6698772.A11 6698772	£2.84	£3.41
340 - HANDLE KNOB A COMP. TILL Z063200 HIT-6691199.A0 6691199	-
341 - TILL Z063200 NO LONGER AVAILABLE HIT-000000.A4028 000000	-
342 - SPECIAL BOLT TILL Z063200 HIT-6687990.A0 6687990	£1.67	£2.00
343 - S.WASHER 6 TILL Z063200 HIT-6684826.A14 6684826	£1.67	£2.00
344 - HEX HOLE BUTTON SCREW 6X15 HIT-6695079.A3 6695079	£1.67	£2.00
345A - GEAR SET PN SINCE Z063201 HIT-6696411.A7 6696411	£97.03	£116.44
346 - HANDLE KNOB TILL Z063200 HIT-6691201.A0 6691201	-
346A - HANDLE KNOB A COMP. SINCE Z063201 HIT-6691200.A0 6691200	£12.10	£14.52
347 - GEAR SHAFT TILL Z063200 HIT-6688958.A0 6688958	£37.82	£45.38
348 - SPECIAL NUT TILL Z063200 HIT-6689753.A0 6689753	-
*349 - SHIM TILL Z063200 HIT-6686483.A0 6686483	-
*349 - SHIM TILL Z063200 HIT-6686484.A0 6686484	-
*349 - SHIM TILL Z063200 HIT-6686485.A0 6686485	-
350 - COLLOR 26.8 TILL Z063200 HIT-6686752.A0 6686752	-
351 - GREASE STOP (B) HIT-6686659.A12 6686659	£1.67	£2.00
352 - NUT TILL Z063200 HIT-6685166.A11 6685166	£3.62	£4.35
353 - WASHER 1.6 W TILL Z063200 HIT-6692945.A0 6692945	-
354 - RETAINING RING C-TYPE D22 SINCE Z063201 HIT-6695293.A23 6695293	£1.67	£2.00
355 - SPECIAL WASHER B SINCE D038101 HIT-6684822.A25 6684822	£1.67	£2.00
356 - RETAINING RING C-TYPE D22 SINCE Z063201 HIT-6695293.A24 6695293	£1.67	£2.00
357 - HANDLE SINCE Z063201 HIT-6688089.A13 6688089	£7.75	£9.30
358 - GREASE STOP (D) SINCE Z063201 HIT-6686669.A12 6686669	£1.67	£2.00
359 - PLUS BOLT 6X14 SINCE Z063201 HIT-6695016.A0 6695016	-
*360 - HEX.NUT 6 SINCE Z063201 HIT-6684835.A34 6684835	£1.67	£2.00
*360 - HEX.NUT 6 TILL D038100 HIT-6684835.A35 6684835	£1.67	£2.00
360A - LOCK NUT 6 UPS-P SINCE D038101 HIT-6695175.A46 6695175	£1.67	£2.00
361 - SUPPORT PLATE SINCE D038101 HIT-6690744.A14 6690744	£17.82	£21.39
362 - BOLT WASHER 6 SINCE D038101 HIT-6684639.A138 6684639	£1.67	£2.00
381 - CAM SHAFT COMP. HIT-6686790.A5 6686790	£62.78	£75.33
382 - CAM ROD HIT-6686809.A9 6686809	£11.92	£14.30
383 - CAM-ROD GUIDE PLATE HIT-6686611.A15 6686611	£2.98	£3.57
384 - CUTTER GUIDE TILL Z063200 HIT-6687128.A0 6687128	£22.29	£26.75
384A - CUTTER GUIDE TILL D106450 HIT-6687124.A0 6687124	-
384B - CUTTER GUIDE 625.5MM SINCE D106451 HIT-6687125.A0 6687125	£37.68	£45.21
385 - CUTTER B TILL D106450 HIT-6687103.A0 6687103	-
385A - CUTTER (A) SINCE D106451 HIT-6687079.A2 6687079	£46.75	£56.10
386 - CUTTER FIXING BOLT A TILL Z063200 HIT-6687160.A4 6687160	£1.67	£2.00
386A - FIXING BOLT A M6 SINCE Z063201 HIT-6687158.A0 6687158	£1.67	£2.00
387 - WASHER 7 BLACK HIT-6687187.A1 6687187	£1.67	£2.00
388 - CUTTER FIXING NUT TILL Z063200 HIT-6687156.A3 6687156	£1.67	£2.00
*388A - FLANGE NUT 6 TILL D038100 HIT-6695170.A51 6695170	£1.67	£2.00
*388A - FLANGE NUT 6 SINCE D038101 HIT-6695170.A52 6695170	£1.67	£2.00
*389 - HEX HOLE FLUSH SCREW 6X16 TILL Z063200 HIT-6695073.A16 6695073	£1.67	£2.00
*389 - HEX HOLE FLUSH SCREW 6X16 SINCE Z063201 HIT-6695073.A17 6695073	£1.67	£2.00
390 - GREASE SEAL A TILL Z063200 HIT-6686654.A4 6686654	£1.67	£2.00
390A - GREASE STOP (A) SINCE Z063201 HIT-6686647.A16 6686647	£1.67	£2.00
391 - CAM ROD PLATE HIT-6686826.A13 6686826	£1.67	£2.00
392 - GEAR CASE COVER B HIT-6689172.A5 6689172	£15.41	£18.49
393 - BALL BEARING 608 ZZ C3 HIT-6695547.A4 6695547	£10.17	£12.20
394 - HEX. HOLE BOLT 4X10S HIT-6695484.A8 6695484	£1.67	£2.00
395 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A17 6684595	£1.67	£2.00
396 - CUTTER COVER TILL D106450 HIT-6687311.A0 6687311	-
396A - CUTTER COVER SINCE D106451 HIT-6687301.A6 6687301	-
397 - CUTTER FIXING BOLT B SINCE Z063201 HIT-6687162.A0 6687162	£1.67	£2.00
398 - HEX. HOLE FLUSH BOLT 6X25 SINCE Z063201 HIT-6695075.A31 6695075	£1.67	£2.00
399 - GREASE STOP (C) SINCE Z063201 HIT-6686666.A14 6686666	-
400 - SPACER SINCE Z063201 HIT-6688633.A12 6688633	-
401A - PROTECTION PLATE SINCE D106451 HIT-6601208.A6 6601208	-
402 - LOCK NUT 6 UPS-P SINCE D038101 HIT-6695175.A45 6695175	£1.67	£2.00
403 - BOLT WASHER 6 SINCE D038101 HIT-6684639.A137 6684639	£1.67	£2.00
501 - COMBI. BOX SPANNER 10X19 1 HIT-6685997.A7 6685997	-
502 - HEX. BAR WRENCH 4MM HIT-6684813.A59 6684813	-
503 - SHOULDER BELT SINCE C026901 HIT-6692867.A11 6692867	£8.37	£10.04
601 - S?START MARK HIT-6694472.A9 6694472	-
602 - SYMBOL MARK TPH-230S HIT-6694642.A0 6694642	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TPH-230S Engine Pole Hedge Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TPH-230S Engine Pole Hedge Trimmer Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TPH-230S Engine Pole Hedge Trimmer Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
