Hitachi / Hikoki TPH-270SS Engine Pole Hedge Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TPH-270SS Engine Pole Hedge Trimmer

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A22 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A31 6699319	-
3 - CYLINDER SET HIT-6685493.A7 6685493	£72.13	£86.56
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A50 6684586	-
5 - CYLINDER GASKET T=1.0 HIT-6685750.A1 6685750	£2.81	£3.37
6 - PISTON RING HIT-6686121.A6 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A14 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A91 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A30 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A13 6686219	£121.07	£145.28
12 - LEAD WIRE ASS'Y HIT-6687965.A4 6687965	£4.26	£5.11
13 - HEX. HOLE BOLT M4X18/WS TILL H124450 HIT-6684599.A51 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE H124451 HIT-6695407.A21 6695407	-
14 - IGNITION COIL ASS'Y MB-55 HIT-6687684.A8 6687684	£35.79	£42.95
*21 - GEAR SHAFT SHIM 0.10 HIT-6689177.A2 6689177	-
*21 - GEAR SHAFT SHIM 0.15 HIT-6689178.A33 6689178	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A41 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A40 6684605	-
22 - MAGNETO ROTOR COMP. HIT-6687384.A6 6687384	-
23 - HEX. NUT M8 HIT-6684612.A65 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A56 6684611	-
25 - CRANK CASE ASS'Y HIT-6684905.A7 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A194 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A13 6684608	£5.70	£6.84
28 - CRANK CASE GASKET HIT-6684904.A13 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A42 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A23 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A21 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT M5X25WS HIT-6695515.A44 6695515	£1.67	£2.00
44 - CARBURETOR GASKET HIT-6684615.A19 6684615	£1.67	£2.00
45 - CABURETOR SET WYJ-431 HIT-6690519.A2 6690519	£113.54	£136.25
46 - CLEANER BODY COMP. HIT-6690120.A2 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A6 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690421.A10 6690421	£14.48	£17.38
49 - COVER FIXING BOLT COMP. HIT-6698730.A15 6698730	£5.52	£6.63
50 - SCREW 5X57/S HIT-6695353.A5 6695353	£1.67	£2.00
51 - SMALL WASHER 5 HIT-6684864.A122 6684864	-
52 - CHOKE LEVER 1.5 HIT-6691281.A5 6691281	£1.67	£2.00
53 - CHOKE CONTROL LEVER HIT-6691239.A16 6691239	£2.98	£3.57
54 - TANK WHT HIT-6691602.A14 6691602	£13.82	£16.59
55 - COLLAR C HIT-6684623.A11 6684623	£1.67	£2.00
56 - RETURN GROMMET HIT-6684627.A104 6684627	£1.67	£2.00
57 - FUEL PIPE 3X5X65 HIT-6684626.A13 6684626	£1.67	£2.00
58A - PUMP FILTER BODY COMP HIT-66A3864.A94 66A3864	-
59 - CLIP D6 HIT-6685198.A78 6685198	-
60 - SHIELD TUBE 3X5X180 HIT-6684618.A19 6684618	£6.12	£7.35
61 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A43 6684634	£1.67	£2.00
62 - TANK CAP ASS'Y HIT-6685049.A4 6685049	£9.94	£11.93
63 - TANK CAP CHAIN HIT-6684625.A46 6684625	-
64 - STAND HIT-6694787.A45 6694787	£3.56	£4.27
65 - TAP SCREW 4X14 P HIT-6695280.A21 6695280	£1.67	£2.00
66 - BOLT WASHER M4 HIT-6685070.A31 6685070	£1.67	£2.00
71 - CYLINDER COVER HIT-6685690.A2 6685690	£5.70	£6.84
72 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A36 6695504	£1.67	£2.00
73 - HEX. HOLE BOLT M6X55 HIT-6684638.A26 6684638	£1.67	£2.00
74 - BOLT WASHER 6 HIT-6684639.A62 6684639	£1.67	£2.00
75 - MUFFLER SET HIT-6692498.A0 6692498	£25.72	£30.86
76 - MUFFLER GASKET HIT-6692732.A19 6692732	£1.67	£2.00
77 - MUFFLER PROTECTOR HIT-6692813.A2 6692813	£8.89	£10.67
78 - HEX. HOLE BOLT 4X18WS TILL H124450 HIT-6695508.A46 6695508	£1.67	£2.00
78A - SCREW 4X18/PS SINCE H124451 HIT-6695375.A17 6695375	-
79 - PLUG CAP HIT-6688345.A5 6688345	£4.99	£5.99
80 - CLUTCH WASHER B HIT-6684642.A29 6684642	£1.67	£2.00
81 - CLUTCH SHOE COMP. HIT-6684643.A7 6684643	£12.01	£14.41
82 - CLUTCH SPRING HIT-6684644.A17 6684644	£3.12	£3.74
83 - CLUTCH PLATE A 0.5 HIT-6684645.A8 6684645	£1.67	£2.00
84 - STEP BOLT HIT-6684646.A27 6684646	£3.72	£4.46
85 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A44 6684634	£1.67	£2.00
86 - BENT WASHER 8 HIT-6684648.A58 6684648	£1.67	£2.00
87 - CLUTCH SET ASS'Y HIT-6699640.A1 6699640	£15.92	£19.10
88 - TAPPING SCREW D4.5X16 HIT-6684636.A16 6684636	£1.67	£2.00
89 - HEAT SHIELD HIT-6687264.A7 6687264	-
101B - RECOIL STARTER BODY ASS'Y INCLUD.103-109 HIT-6601570.A3 6601570	£23.15	£27.78
103 - STARTER ROPE 3.5X860 HIT-6684674.A50 6684674	£5.70	£6.84
104 - RECOIL SPRING HIT-6684675.A69 6684675	£8.82	£10.58
105A - STARTER ROPE REEL SINCE TL026141 HIT-6699997.A23 6699997	-
106 - DAMPER SPRING HIT-6684677.A65 6684677	£5.70	£6.84
107A - CAM PLATE SINCE TL026141 HIT-6699996.A66 6699996	£4.28	£5.13
108 - SET SCREW HIT-6684679.A91 6684679	£2.98	£3.57
109 - STARTER HANDLE HIT-6684680.A51 6684680	£5.87	£7.04
110 - STARTER PULLEY ASS'Y HIT-6684681.A64 6684681	£18.16	£21.79
111 - D4E RETAINING RING HIT-6685101.A147 6685101	-
112 - STARTER PAWL SPRING HIT-6684684.A49 6684684	£3.29	£3.95
113 - STARTER PAWL HIT-6684685.A62 6684685	£5.07	£6.08
114 - HEX. HOLE BOLT 4X18WS TILL H124450 HIT-6695508.A47 6695508	£1.67	£2.00
114A - SCREW 4X18/PS SINCE H124451 HIT-6695375.A18 6695375	-
115 - CAMPLATE ASS'Y TILL TL026140 HIT-6699691.A45 6699691	£7.75	£9.30
121 - PUMP BODY COMP. HIT-6684879.A1 6684879	£35.37	£42.44
122 - PRIMING PUMP COMP. HIT-6684687.A37 6684687	£9.27	£11.12
123 - DIAPHRAGM COVER HIT-6684688.A63 6684688	£5.70	£6.84
124 - PRIMING BODY HIT-6684689.A36 6684689	£5.87	£7.04
125 - METERING DIAPHRAGM COMP. HIT-6690830.A10 6690830	£14.58	£17.50
126 - DIAPHRAGM GASKET HIT-6684691.A37 6684691	£5.70	£6.84
127 - PUMP DIAPHRAGM HIT-6684693.A89 6684693	£5.70	£6.84
128 - PUMP GASKET HIT-6684692.A65 6684692	£17.28	£20.73
129 - MAIN JET #43 HIT-6691848.A13 6691848	£8.77	£10.52
130 - O-RING HIT-6684695.A109 6684695	£1.67	£2.00
131 - STOP RING HIT-6684696.A96 6684696	-
132 - SWIVEL HIT-6684697.A89 6684697	-
133 - THROTTLE SET SCREW HIT-6684870.A75 6684870	-
134 - CABLE ADJUSTER STAY HIT-6684873.A3 6684873	-
135 - LOCK NUT M6 HIT-6684872.A87 6684872	-
136 - CABLE ADJUSTER HIT-6684871.A3 6684871	-
137 - CLEANER PACKING HIT-6684875.A4 6684875	-
138 - SET SCREW HIT-6684699.A60 6684699	-
139 - THRUST WASHER HIT-6684874.A76 6684874	-
140 - INLET SCREEN HIT-6684700.A112 6684700	-
151 - CLUTCH DRUM COMP. HIT-6688580.A5 6688580	£16.79	£20.15
152 - STOP RING C-12 OUTER HIT-6684664.A33 6684664	£1.67	£2.00
153 - CUSHION RUBBER HIT-6691823.A8 6691823	£3.56	£4.27
154 - HEX. HOLE BOLT 5X16 HIT-6695046.A16 6695046	£1.67	£2.00
155 - HEX. HOLE BOLT M5X25/S HIT-6684709.A146 6684709	£1.67	£2.00
156 - FAN CASE COMP. HIT-6686959.A5 6686959	£25.96	£31.15
157 - PIPE HOLDER 1 HIT-6689651.A21 6689651	£8.88	£10.66
158 - WASHER M5 (BLACK) HIT-6684918.A92 6684918	£1.67	£2.00
159 - GEAR CASE WASHER HIT-6689159.A53 6689159	-
160 - METAL FITTING HIT-6689664.A8 6689664	£6.12	£7.35
181 - DRIVE SHAFT 633L HIT-6689439.A1 6689439	-
182 - DRIVE SHAFT PIPE 600L HIT-6689303.A0 6689303	-
183 - BUSH ASS'Y HIT-6684831.A14 6684831	-
184 - HANGER D24 HIT-6689277.A3 6689277	-
185 - BRACKET A HIT-6688103.A1 6688103	-
186 - BRACKET B HIT-6688104.A5 6688104	-
187 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A37 6684714	£1.67	£2.00
189 - NUT M5 (BLACK) HIT-6685075.A11 6685075	-
190 - HEX.NUT 6 HIT-6684835.A14 6684835	£1.67	£2.00
191 - WASHER 6 HIT-6695194.A3 6695194	-
192 - FRONT HANDLE HIT-6688096.A4 6688096	£16.62	£19.94
193 - HEX. HOLE BOLT 5X55 HIT-6695056.A5 6695056	-
194 - WASHER M5 (BLACK) HIT-6684918.A93 6684918	£1.67	£2.00
195 - SPRING WASHER 5 HIT-6684834.A43 6684834	£1.67	£2.00
196 - THROTTLE LEVER ASS'Y 1 HIT-6693764.A0 6693764	£45.00	£54.00
197 - THROTTLE WIRE COMP. HIT-6693978.A2 6693978	£22.29	£26.75
198 - THROTTLE WIRE HIT-6694022.A8 6694022	-
199 - STOP SWITCH COMP. HIT-6687459.A9 6687459	£17.33	£20.80
200 - PROTECTION TUBE 7X175 HIT-6687526.A9 6687526	-
201 - TRIGGER LOCK OUT HIT-6684721.A24 6684721	£5.17	£6.20
202 - RETURN SPRING HIT-6684722.A25 6684722	£1.67	£2.00
203 - THROTTLE STOPPER COMP. HIT-6693807.A1 6693807	-
204 - SCREW M5X20 HIT-6684803.A25 6684803	-
205 - CONTAL NUT 5 HIT-6684727.A23 6684727	£1.67	£2.00
206 - SCREW M4X20 (BLACK) HIT-6684725.A17 6684725	-
207 - THROTTLE LEVER HIT-6684804.A5 6684804	£6.86	£8.23
221 - GEAR CASE A 1 HIT-6688653.A6 6688653	£38.36	£46.03
222 - BALL BEARING 6901ZZ 2 HIT-6695582.A11 6695582	£15.31	£18.37
223 - STOP RING S-12 1 HIT-6695302.A1 6695302	£1.67	£2.00
224 - STOP RING C-24 1 HIT-6684732.A23 6684732	£1.67	£2.00
225 - BALL BEARING 608ZZC3 HIT-6698772.A22 6698772	£2.84	£3.41
226 - RETAINING RING C-TYPE D22 HIT-6695293.A9 6695293	£1.67	£2.00
227 - GREASE NIPPLE COMP. HIT-6688643.A44 6688643	£1.67	£2.00
228 - HEX. HOLE BOLT 5X10 HIT-6695042.A34 6695042	£1.67	£2.00
229 - HEX. HOLE BOLT M5X25/S HIT-6684709.A145 6684709	£1.67	£2.00
230 - HEX. HOLE BOLT 6X12 HIT-6695078.A5 6695078	£1.67	£2.00
231 - SPECIAL WASHER B HIT-6684822.A37 6684822	£1.67	£2.00
232 - GEAR CASE B HIT-6695981.A3 6695981	£40.62	£48.75
233 - BALL BEARING #6000DD 1 HIT-6695528.A1 6695528	-
234 - RETAINING RING C-TYPE D26 HIT-6695294.A29 6695294	-
235 - SPECIAL WASHER B HIT-6684822.A38 6684822	£1.67	£2.00
236 - RETAINING RING E-TYPE D6 HIT-6695310.A7 6695310	£1.67	£2.00
237 - GEAR CASE COVER (A) HIT-6689167.A10 6689167	-
238 - HEX HOLE BOLT 4X8 HIT-6695035.A7 6695035	-
239 - BALL BEARING 608ZZC3 HIT-6698772.A23 6698772	£2.84	£3.41
240 - RETAINING RING C-TYPE D22 HIT-6695293.A8 6695293	£1.67	£2.00
241 - HANDLE HIT-6688089.A0 6688089	£7.75	£9.30
242 - HEX HOLE BUTTON SCREW 6X15 HIT-6695079.A15 6695079	£1.67	£2.00
243 - GREASE STOP (D) HIT-6686669.A4 6686669	£1.67	£2.00
244 - GEAR SET PN HIT-6696411.A3 6696411	£97.03	£116.44
245 - HANDLE KNOB A COMP. HIT-6691200.A7 6691200	£12.10	£14.52
246 - PLUS BOLT 6X14 HIT-6695016.A14 6695016	-
247 - LOCK NUT 6 UPS-P HIT-6695175.A19 6695175	£1.67	£2.00
248 - SUPPORT PLATE HIT-6690744.A4 6690744	£17.82	£21.39
249 - GREASE STOP (B) HIT-6686659.A4 6686659	£1.67	£2.00
250 - ANGLE LIMITER HIT-6688159.A1 6688159	-
251 - BOLT WASHER 6 HIT-6684639.A63 6684639	£1.67	£2.00
261 - CAM SHAFT COMP. HIT-6686790.A10 6686790	£62.78	£75.33
262 - CAM ROD HIT-6686809.A3 6686809	£11.92	£14.30
263 - CAM-ROD GUIDE PLATE HIT-6686611.A2 6686611	£2.98	£3.57
264 - CUTTER GUIDE 625.5MM HIT-6687125.A11 6687125	£37.68	£45.21
265 - CUTTER (A) HIT-6687079.A9 6687079	£46.75	£56.10
266 - FIXING BOLT A M6 HIT-6687158.A43 6687158	£1.67	£2.00
267 - WASHER 7 BLACK HIT-6687187.A32 6687187	£1.67	£2.00
268 - FLANGE NUT 6 HIT-6695170.A14 6695170	£1.67	£2.00
269 - HEX HOLE FLUSH SCREW 6X16 HIT-6695073.A6 6695073	£1.67	£2.00
270 - GREASE STOP (A) HIT-6686647.A6 6686647	£1.67	£2.00
271 - CAM ROD PLATE HIT-6686826.A10 6686826	£1.67	£2.00
272 - GEAR CASE COVER B HIT-6689172.A2 6689172	£15.41	£18.49
273 - BALL BEARING 608 ZZ C3 HIT-6695547.A19 6695547	£10.17	£12.20
274 - HEX. HOLE BOLT 4X10S HIT-6695484.A31 6695484	£1.67	£2.00
275 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A36 6684595	£1.67	£2.00
276 - CUTTER COVER HIT-6687301.A11 6687301	-
277 - CUTTER FIXING BOLT B HIT-6687162.A18 6687162	£1.67	£2.00
278 - HEX. HOLE FLUSH BOLT 6X25 HIT-6695075.A14 6695075	£1.67	£2.00
279 - GREASE STOP (C) HIT-6686666.A1 6686666	-
280 - SPACER HIT-6688633.A9 6688633	-
281A - PROTECTION PLATE HIT-6601208.A0 6601208	-
282 - LOCK NUT 6 UPS-P HIT-6695175.A20 6695175	£1.67	£2.00
283 - BOLT WASHER 6 HIT-6684639.A65 6684639	£1.67	£2.00
501 - COMBI. BOX SPANNER 10X19 1 HIT-6685997.A15 6685997	-
502 - HEX. BAR WRENCH 4MM HIT-6684813.A37 6684813	-
601 - SYMBOL MARK HIT-6601107.A0 6601107	-
602 - S?START MARK HIT-6694472.A4 6694472	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TPH-270SS Engine Pole Hedge Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TPH-270SS Engine Pole Hedge Trimmer Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TPH-270SS Engine Pole Hedge Trimmer Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
