1 - ARMATURE COMPL. 230V
MET-310011100.A3
310011100
|
£73.52
|
£88.23
|
|
|
2 - FELDPAKET VOLLST 230V
MET-311012120.A3
311012120
|
-
|
|
|
|
3 - ELECTRONIC SWITCH WITHOUT DIAL 230V
MET-343410360.A2
343410360
|
£32.88
|
£39.45
|
|
|
4 - CABLE W.CEE PLUG
MET-344499520.A1
344499520
|
-
|
|
|
|
5 - CABLE SLEEVE
MET-344101140.A155
344101140
|
£3.82
|
£4.59
|
|
|
6 - CABLE CLIP
MET-343362490.A829
343362490
|
£3.20
|
£3.84
|
|
|
7 - BRUSH HOLDER COMPL. 230 V
MET-316054740.A9
316054740
|
£9.62
|
£11.54
|
|
|
9 - INSULATING HOSE
MET-339040970.A6
339040970
|
-
|
|
|
|
10 - BALL BEARING 6X 19X 6
MET-143115810.A112
143115810
|
£7.04
|
£8.45
|
|
|
11 - O-RING
MET-143192430.A91
143192430
|
£3.20
|
£3.84
|
|
|
12 - INTERMEDIATE FLANGE
MET-343434360.A3
343434360
|
-
|
|
|
|
13 - BALL BEARING 10X19X5
MET-143115570.A7
143115570
|
-
|
|
|
|
14 - MOTOR HOUSING
MET-315013610.A2
315013610
|
-
|
|
|
|
15 - SEALING RING
MET-343434430.A1
343434430
|
-
|
|
|
|
16 - HOOK
MET-343434590.A4
343434590
|
-
|
|
|
|
17 - HOUSING W.COVER
MET-343434340.A8
343434340
|
-
|
|
|
|
18 - SEAL
MET-344099610.A13
344099610
|
-
|
|
|
|
19 - PRESSURE SPRING
MET-342003960.A6
342003960
|
-
|
|
|
|
20 - AXIAL NEEDLE BEARING
MET-143113820.A6
143113820
|
£9.62
|
£11.54
|
|
|
21 - RUBBER BUFFER
MET-344099600.A3
344099600
|
-
|
|
|
|
22 - RUBBER PLUG
MET-344093350.A3
344093350
|
£1.50
|
£1.80
|
|
|
23 - O-RING
MET-143193920.A22
143193920
|
£8.37
|
£10.04
|
|
|
24 - CLAW WHEEL
MET-340013030.A0
340013030
|
-
|
|
|
|
25 - CLAW DISC
MET-341161570.A8
341161570
|
-
|
|
|
|
26 - TIEFENANSCHLAG VOLLST.
MET-316054470.A6
316054470
|
£22.96
|
£27.55
|
|
|
27 - BALL
MET-143120020.A3
143120020
|
£3.20
|
£3.84
|
|
|
28 - THRUST WASHER
MET-143114760.A8
143114760
|
£2.94
|
£3.53
|
|
|
29 - SLEEVE
MET-343434410.A8
343434410
|
-
|
|
|
|
30 - SELF-TAP FILL H SCREW
MET-141116020.A48
141116020
|
£3.20
|
£3.84
|
|
|
31 - SELF-TAP. FILL. H. SCREW
MET-141116990.A178
141116990
|
£3.20
|
£3.84
|
|
|
32 - SELF-TAP. FILL. H. SCREW
MET-141124570.A5
141124570
|
-
|
|
|
|
33 - SELF-TAPP. FILL. H. SCREW
MET-141119900.A28
141119900
|
£1.50
|
£1.80
|
|
|
34 - RATING PLATE
MET-338063160.A0
338063160
|
-
|
|
|
|
35 - TYPE LABEL SE 4000
MET-338125830.A0
338125830
|
-
|
|
|
|
37 - BIT HOLDING SLEEVES
MET-316055470.A3
316055470
|
£8.37
|
£10.04
|
|
|
38 - GEAR HOUSING COMPL.
MET-316057010.A0
316057010
|
£30.06
|
£36.07
|
|
|
39 - GEAR FLANGE COMPL.
MET-316057030.A3
316057030
|
-
|
|
|
|
41 - SHAFT
MET-341604640.A0
341604640
|
-
|
|
|
|
882 - GREASE FG 126
MET-344130800.A88
344130800
|
£17.55
|
£21.06
|
|
|
1001 - WIRING DIAGRAM 230V
MET-338505900.A4
338505900
|
-
|
|
|
