1 - MOTOR HOUSING
BSD-3605108172.A1
3605108172
|
-
|
|
|
|
2 - STATOR 320W
BSD-3604090029.A19
3604090029
|
£21.52
|
£25.83
|
|
|
3 - ROTOR
BSD-3604220039.A11
3604220039
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700065.A9
3605700065
|
£10.10
|
£12.12
|
|
|
6 - GROOVE BALL BEARING 8x22x7
BSD-3600905124.A2
3600905124
|
£14.91
|
£17.89
|
|
|
7 - BEARING FLANGE
BSD-3605700143.A1
3605700143
|
£48.38
|
£58.06
|
|
|
8 - GROOVE BALL BEARING 7x22x7
BSD-3600905122.A16
3600905122
|
£5.58
|
£6.70
|
|
|
9 - O-RING 4.0x1.0 MM
BSD-3600210015.A72
3600210015
|
£3.72
|
£4.47
|
|
|
12 - SHIM
BSD-3600100030.A32
3600100030
|
£1.75
|
£2.10
|
|
|
27 - SHIM
BSD-3600100090.A9
3600100090
|
£4.26
|
£5.11
|
|
|
30 - SPACER RING
BSD-3600209003.A12
3600209003
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=14
BSD-3606316093.A132
3606316093
|
£2.61
|
£3.13
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A29
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A367
3603201000
|
£1.75
|
£2.10
|
|
|
34 - RETAINING SNAP RING
BSD-3600400008.A9
3600400008
|
£18.96
|
£22.75
|
|
|
35 - NEEDLE ROLLER A 3x15.8G2DIN5402
BSD-1903201044.A62
1903201044
|
£2.33
|
£2.80
|
|
|
37 - SHIM 0.3 MM
BSD-1600101618.A71
1600101618
|
£2.61
|
£3.13
|
|
|
38 - DRIVE SHAFT
BSD-3603050005.A9
3603050005
|
£48.38
|
£58.06
|
|
|
39 - CYLINDRICAL GEAR Z=14
BSD-3606316073.A10
3606316073
|
£2.61
|
£3.13
|
|
|
41 - GROOVE BALL BEARING
BSD-3600900011.A4
3600900011
|
£27.23
|
£32.68
|
|
|
42 - O-RING 28x2 MM
BSD-1900210327.A10
1900210327
|
£4.26
|
£5.11
|
|
|
43 - O-RING 30x2.5 MM
BSD-1900210131.A99
1900210131
|
£4.26
|
£5.11
|
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A112
2600210018
|
£3.72
|
£4.47
|
|
|
45 - SHIM
BSD-2600102036.A71
2600102036
|
£2.61
|
£3.13
|
|
|
47 - GROOVE BALL BEARING
BSD-3600905015.A63
3600905015
|
£16.41
|
£19.69
|
|
|
48 - THREADED BUSHING
BSD-3600390003.A57
3600390003
|
£12.04
|
£14.45
|
|
|
50 - SHIM
BSD-2600102036.A72
2600102036
|
£2.61
|
£3.13
|
|
|
56 - CONNECTION HOUSING
BSD-3603462013.A1
3603462013
|
£46.82
|
£56.18
|
|
|
60 - STRAINER
BSD-3600002001.A106
3600002001
|
£2.61
|
£3.13
|
|
|
66 - STRAIGHT PIN DIN 7-9 m6x16-S 20 K
BSD-2917510039.A0
2917510039
|
£1.32
|
£1.58
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A489
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110331.A45
3601110331
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A486
3601119236
|
£3.72
|
£4.47
|
|
|
650 - SILENCER
BSD-3607000023.A21
3607000023
|
£11.30
|
£13.56
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030244.A30
3607030244
|
£23.86
|
£28.63
|
|
|
828 - ASSEMBLY OF SERVICE PARTS
BSD-3607031322.A15
3607031322
|
£63.50
|
£76.20
|
|
|
840 - O-RING
BSD-3607010005.A15
3607010005
|
-
|
|
|
|
865 - PARTS SET
BSD-3607010020.A82
3607010020
|
£8.67
|
£10.41
|
|
