1 - MOTOR HOUSING
BSD-3605108145.A13
3605108145
|
£27.23
|
£32.68
|
|
|
2 - POLE SHOE 220V
BSD-1604220145.A2
1604220145
|
-
|
|
|
|
2/20 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A305
1901350003
|
£1.75
|
£2.10
|
|
|
3 - ARMATURE 220V
BSD-1604010157.A4
1604010157
|
-
|
|
|
|
4 - SWITCH
BSD-1607200078.A82
1607200078
|
£40.80
|
£48.96
|
|
|
4 - SWITCH
BSD-1607200037.A7
1607200037
|
£45.67
|
£54.80
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1375
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A904
1601302014
|
£2.61
|
£3.13
|
|
|
9 - STICKER
BSD-1601110046.A35
1601110046
|
£1.75
|
£2.10
|
|
|
11 - SUPPRESSION CAPACITOR
BSD-1607328012.A73
1607328012
|
-
|
|
|
|
11/20 - TERMINAL LUG
BSD-1601353003.A220
1601353003
|
-
|
|
|
|
12 - SEALING PLATE
BSD-1601015013.A83
1601015013
|
£1.75
|
£2.10
|
|
|
13 - REFERENCE PLATE
BSD-1601110070.A7
1601110070
|
-
|
|
|
|
16 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A573
1602381001
|
-
|
|
|
|
18 - SPIRAL SPRING
BSD-1604652006.A96
1604652006
|
£1.75
|
£2.10
|
|
|
19 - TAB WASHER
BSD-1601030022.A36
1601030022
|
£1.75
|
£2.10
|
|
|
20 - RUBBER BUSHING
BSD-1600502020.A64
1600502020
|
£2.61
|
£3.13
|
|
|
21 - BALL BEARING 7x19x6
BSD-2600905032.A829
2600905032
|
£5.30
|
£6.36
|
|
|
22 - SEALING CAP
BSD-3605500063.A43
3605500063
|
£4.26
|
£5.11
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502015.A24
1600502015
|
-
|
|
|
|
24 - INTERMEDIATE RING
BSD-1600202034.A38
1600202034
|
-
|
|
|
|
25 - INTERMEDIATE RING
BSD-1600206018.A37
1600206018
|
-
|
|
|
|
26 - INTERMEDIATE BEARING
BSD-1605820214.A7
1605820214
|
-
|
|
|
|
27 - RETAINING RING 35 DIN 9045
BSD-2916600018.A17
2916600018
|
£1.75
|
£2.10
|
|
|
28 - GROOVE BALL BEARING
BSD-1600905003.A28
1600905003
|
-
|
|
|
|
29 - FELT DISC
BSD-1600108003.A146
1600108003
|
£1.32
|
£1.58
|
|
|
30 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A563
2600910001
|
£4.26
|
£5.11
|
|
|
31 - CYLINDRICAL GEAR Z=41
BSD-1606317080.A7
1606317080
|
£27.23
|
£32.68
|
|
|
32 - SPINDLE BEARING M14
BSD-1605806368.A24
1605806368
|
£72.18
|
£86.62
|
|
|
32/2 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A137
2917500121
|
£1.75
|
£2.10
|
|
|
33 - RETAINING SNAP RING
BSD-1610500004.A39
1610500004
|
-
|
|
|
|
34 - FELT DISC
BSD-1600108058.A7
1600108058
|
£1.32
|
£1.58
|
|
|
35 - RETAINING SNAP RING
BSD-3607030355.A52
3607030355
|
£18.96
|
£22.75
|
|
|
36 - DRILLING SPINDLE 5/8
BSD-1603523087.A16
1603523087
|
£48.38
|
£58.06
|
|
|
37 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A285
2916650006
|
£1.75
|
£2.10
|
|
|
38 - SHIM 0.5 MM
BSD-1600100631.A335
1600100631
|
£1.75
|
£2.10
|
|
|
39 - SPINDLE WITH GEAR Z=14/24/33
BSD-1606309064.A0
1606309064
|
-
|
|
|
|
40 - NEEDLE BEARING
BSD-1600910013.A183
1600910013
|
£5.58
|
£6.70
|
|
|
41 - TOOTHED SHAFT Z=17
BSD-1606309063.A16
1606309063
|
£45.67
|
£54.80
|
|
|
42 - SHIM 0.6 MM
BSD-1600101647.A33
1600101647
|
£2.16
|
£2.59
|
|
|
43 - CYLINDRICAL GEAR Z=43
BSD-1606317082.A1
1606317082
|
£37.27
|
£44.72
|
|
|
44 - CYLINDRICAL GEAR Z=32
BSD-1606317074.A18
1606317074
|
£31.64
|
£37.97
|
|
|
45 - COMPRESSION SPRING
BSD-1604611022.A25
1604611022
|
£1.75
|
£2.10
|
|
|
46 - BALL DIN 5401-5 G28
BSD-1903230009.A131
1903230009
|
£1.75
|
£2.10
|
|
|
47 - CONTROL SHAFT Z=10
BSD-1606325027.A60
1606325027
|
£8.67
|
£10.41
|
|
|
48 - O-RING 8x2.5 MM
BSD-1900210105.A17
1900210105
|
£1.75
|
£2.10
|
|
|
49 - CONTROL SHAFT Z=20
BSD-1606325025.A8
1606325025
|
£2.80
|
£3.36
|
|
|
50 - NOTCHED PLATE
BSD-1601038025.A85
1601038025
|
£1.75
|
£2.10
|
|
|
51 - CONTROL LEVER
BSD-1602026044.A0
1602026044
|
£7.36
|
£8.83
|
|
|
55 - TAPPING SCREW B4.8x115 MM
BSD-1603435015.A13
1603435015
|
-
|
|
|
|
56 - TORX OVAL-HEAD SCREW
BSD-2914201527.A17
2914201527
|
£2.16
|
£2.59
|
|
|
57 - TAPPING SCREW B4.8x50 MM
BSD-1603435012.A15
1603435012
|
£1.75
|
£2.10
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A65
2910211011
|
£1.75
|
£2.10
|
|
|
59 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2245
2910211019
|
£1.75
|
£2.10
|
|
|
60 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1579
2910021118
|
£1.75
|
£2.10
|
|
|
61 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A1003
2910211021
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-8.8
BSD-2910021128.A4
2910021128
|
-
|
|
|
|
62 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A252
2910021116
|
£2.16
|
£2.59
|
|
|
63 - COUNTERSUNK-HEAD SCREW AM 4x10 DIN 63-8.8
BSD-2910511120.A29
2910511120
|
-
|
|
|
|
64 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A432
2915011005
|
£1.75
|
£2.10
|
|
|
650 - AUXILIARY HANDLE dia43 MM
BSD-3602025021.A13
3602025021
|
£40.80
|
£48.96
|
|
|
650/1 - AUXILIARY HANDLE M14
BSD-1602025022.A844
1602025022
|
£13.41
|
£16.09
|
|
|
650/1 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A18
1602025030
|
£18.96
|
£22.75
|
|
|
650/2 - SUPPORT CLAMP
BSD-1618040077.A169
1618040077
|
-
|
|
|
|
650/3 - STUD BOLT M8
BSD-1613521001.A146
1613521001
|
£5.58
|
£6.70
|
|
|
650/3 - STUD BOLT M8
BSD-1613521001.A147
1613521001
|
£5.58
|
£6.70
|
|
|
650/4 - CLAMPING BAND dia43 MM
BSD-3601038048.A37
3601038048
|
£18.96
|
£22.75
|
|
|
650/5 - STRAIGHT PIN
BSD-1613100012.A233
1613100012
|
£2.61
|
£3.13
|
|
|
650/8 - HANDLE BAR
BSD-3602025022.A38
3602025022
|
£18.96
|
£22.75
|
|
|
651 - KEY CHUCK dia3-16 MM. 5/8
BSD-1608571056.A0
1608571056
|
£48.12
|
£57.74
|
|
|
651/8 - CHUCK WRENCH SG2
BSD-2607950011.A8
2607950011
|
£11.30
|
£13.56
|
|
|
652 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A6
1613001008
|
£8.67
|
£10.41
|
|
|
800 - HANDLE
BSD-3605133012.A126
3605133012
|
-
|
|
|
|
801 - CARBON-BRUSH SET
BSD-1607014126.A21
1607014126
|
£16.41
|
£19.69
|
|
|
805 - POWER SUPPLY CORD
BSD-3607030489.A70
3607030489
|
£31.64
|
£37.97
|
|
|
817 - BRUSH HOLDER
BSD-1604336017.A136
1604336017
|
£7.36
|
£8.83
|
|
|
835 - RETAINING SNAP RING
BSD-3607030355.A54
3607030355
|
£18.96
|
£22.75
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2157
160111A3H3
|
£2.61
|
£3.13
|
|
