4 - SWITCH
BSD-160720035A.A31
160720035A
|
£11.30
|
£13.56
|
|
|
6 - GROMMET
BSD-1600703043.A67
1600703043
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A648
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C2TY.A0
160111C2TY
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A608
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A312
1600905032
|
£5.58
|
£6.70
|
|
|
24 - COVER
BSD-1605500275.A24
1605500275
|
£2.80
|
£3.36
|
|
|
25 - HOUSING COVER
BSD-1605500276.A0
1605500276
|
£8.67
|
£10.41
|
|
|
27 - RUBBER RING
BSD-1600206025.A601
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591047.A33
1600591047
|
£2.16
|
£2.59
|
|
|
30 - AIR DISTRIBUTOR
BSD-1600591048.A51
1600591048
|
£2.61
|
£3.13
|
|
|
31 - BRUSH-COVER
BSD-1605500277.A64
1605500277
|
£2.16
|
£2.59
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A150
1600210035
|
£1.75
|
£2.10
|
|
|
34 - BRAKING ELEMENT
BSD-1600A012X9.A12
1600A012X9
|
-
|
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A359
1600136013
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A161
1600136014
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A359
1600136015
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A159
1600136020
|
£3.72
|
£4.47
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A373
1600290016
|
£2.61
|
£3.13
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A356
1600119011
|
£2.16
|
£2.59
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A152
1603300016
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW M4x16-St w/ Precote 85-3
BSD-160343508X.A0
160343508X
|
£1.75
|
£2.10
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1308
2603490023
|
£1.75
|
£2.10
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A124
1603435078
|
£1.75
|
£2.10
|
|
|
54 - TORX OVAL-HEAD SCREW 4x30
BSD-1603414026.A126
1603414026
|
£1.75
|
£2.10
|
|
|
55 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A583
2603490021
|
£1.75
|
£2.10
|
|
|
108 - INSULATING PART
BSD-1600712030.A75
1600712030
|
£1.75
|
£2.10
|
|
|
301/17 - SPIRAL SPRING
BSD-1604652021.A70
1604652021
|
£1.75
|
£2.10
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026091.A40
1602026091
|
£1.75
|
£2.10
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611031.A113
1604611031
|
£2.80
|
£3.36
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319026.A38
1602319026
|
£1.75
|
£2.10
|
|
|
301/48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A154
1613435034
|
£1.75
|
£2.10
|
|
|
343 - CATCH LEVER
BSD-1607000742.A58
1607000742
|
£7.36
|
£8.83
|
|
|
343/44 - COMPRESSION SPRING
BSD-1604611042.A102
1604611042
|
£1.75
|
£2.10
|
|
|
650/1 - AUXILIARY HANDLE M10 ANTI-VIBRATION
BSD-16020250A0.A37
16020250A0
|
£21.42
|
£25.71
|
|
|
651 - PROTECTIVE COVER
BSD-1600A00XK9.A53
1600A00XK9
|
£14.72
|
£17.67
|
|
|
801 - MOTOR HOUSING
BSD-1607000CY2.A27
1607000CY2
|
£18.96
|
£22.75
|
|
|
802 - FIELD ASSEMBLY 230V
BSD-160422053W.A0
160422053W
|
£33.74
|
£40.49
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1600A00D2N.A3
1600A00D2N
|
£81.81
|
£98.17
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000392.A95
1607000392
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A6J5.A1
160111A6J5
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607000V37.A53
1607000V37
|
£14.91
|
£17.89
|
|
|
813 - GROOVE BALL BEARING
BSD-1607000V38.A21
1607000V38
|
£7.36
|
£8.83
|
|
|
816 - BRUSH HOLDER
BSD-1607000V43.A3
1607000V43
|
£3.72
|
£4.47
|
|
|
818 - PAN HEAD SCREW
BSD-1607000V42.A84
1607000V42
|
£1.75
|
£2.10
|
|
|
821 - GEAR HOUSING
BSD-1607000D5C.A3
1607000D5C
|
-
|
|
|
|
828 - PARTS SET
BSD-1607000D5G.A5
1607000D5G
|
-
|
|
|
|
828/04 - O-RING 47.0x1.5 MM
BSD-3600210109.A176
3600210109
|
£2.16
|
£2.59
|
|
|
835 - FAN
BSD-1606610132.A54
1606610132
|
£2.16
|
£2.59
|
|
|
840 - PARTS SET
BSD-1607000D5X.A12
1607000D5X
|
-
|
|
|
|
841 - PARTS SET
BSD-1607000D5Z.A5
1607000D5Z
|
-
|
|
|
|
851 - SPEED GOVERNOR
BSD-16072335D0.A2
16072335D0
|
£46.82
|
£56.18
|
|
|
891 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A918
160202509T
|
£3.72
|
£4.47
|
|
